PM-42
PERIODIC MAINTENANCE SERVICES
SUPPLEMENTAL RESTRAINT SYSTEM
27.Supplemental Restraint System
A: INSPECTION
Check the airbag system in accordance with the result of the self-diagnosis. <Ref. to AB-2, Basic Diagnostic
Procedure.>
1) Ensure that airbag connectors are connected. If not, properly connect. When the ignition switch is turned
ON with the connector(s) disconnected, the airbag warning light blinks to identify the fault.
2) Turn the ignition switch to ON, and connect the airbag diagnosis terminal of the service connector (located
below lower cover) to ground terminal.
3) The warning light blinks to indicate a trouble code (a fault is identified). When the airbag system is in good
order (no trouble codes are stored in the memory), the warning light blinks on and off at 0.6 second intervals
(as long as the diagnosis terminal is connected to ground terminal).
4) When the warning light indicates a trouble code, check the airbag system in accordance with the trouble-
shooting procedure. <Ref. to AB-2, Basic Diagnostic Procedure.>
PM-00103
MPH
