Fuse
panel
Fuse
rating
Circuit
15 10A
. Luggage light
. Keyless unit
16 7.5A
. Illumination
17 15A
. Seat heaters
18 10A
. Backup light
19 7.5A
. Wiper relay
20 10A
. Accessory power outlet
(instrument panel)
21 10A
. Starter relay
22 7.5A
. Air conditioner
. Rear window defogger
relay coil
23 Empty
24 10A
. Audio unit
. Navigation system (if
equipped)
25 15A
. SRS airbag system
26 Empty
27 15A
. Blower fan
28 15A
. Blower fan
29 15A
. Fog light
30 Empty
Fuse
panel
Fuse
rating
Circuit
31 7.5A
. Auto air conditioner unit
. Integrated unit
32 7.5A
. Clutch switch
. Steering lock control
unit
33 7.5A
. Vehicle Dynamics Con-
trol unit
Specifications/Fuses and circuits
– CONTINUED –
12-13
