Subaru LEGACY 2004 - Muffler

EX(H4SO 2.0)-13
EXHAUST
Muffler
5. Muffler
A: REMOVAL
1) Separate the muffler from rear exhaust pipe.
•LH side
• RH side (2.5 L model)
2) Apply a coat of spray type lubricant to mating
area of cushion rubber.
•LH side
• RH side (2.5 L model)
3) Remove the front and rear cushion rubber, and
then remove the muffler.
B: INSTALLATION
Install in the reverse order of removal.
NOTE:
Use a new gasket and self-locking nut.
Tightening torque:
48 N
⋅ m (4.9 kgf-m, 35.4 ft-lb)
•LH side
• RH side (2.5 L model)
C: INSPECTION
1) Make sure there are no exhaust leaks from con-
nections and welds.
2) Make sure there are no holes or rusting.
3) Make sure the cushion rubber is not worn or
cracked.
EX-00222
EX-00218
EX-00220
EX-00221
EX-00222
EX-00218
