Subaru LEGACY 2004 User Manual

IG(H4SO 2.0)-2
IGNITION
General Description
1. General Description
A: SPECIFICATION
1. 2.0 L MODEL
2. 2.5 L MODEL
Item Designation
Ignition coil & ignitor
ASSY
Model CM12-100C
Manufacturer HITACHI
Secondary coil resistance 18.0 kΩ± 20%
Spark plug
Manufacturer and Type CHAMPION: RC10YC4
Thread size (diameter, pitch, length) mm 14, 1.25, 19
Spark plug gap mm (in) 1.0 — 1.1 (0.039 — 0.043)
Electrode Nickel
Item Designation
Ignition coil & ignitor
ASSY
Model FH 0286
Manufacturer DIAMOND
Secondary coil resistance 11.2 kΩ±15%
Spark plug
Manufacturer and Type
EC, EK, K4 model NGK: PFR5B-11
Except for EC, EK,
K4 model
CHAMPION: RC10YC4
Thread size (diameter, pitch, length) mm 14, 1.25, 19
Spark plug gap mm (in) 1.0 — 1.1 (0.039 — 0.043)
Electrode
EC, EK, K4 model Platinum
Except for EC, EK,
K4 model
Nickel
