IN(H4SO 2.0)-5
INTAKE (INDUCTION)
Air Cleaner Element
2. Air Cleaner Element
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Disconnect the connector from mass air flow and
intake air temperature sensor. (2.5 L EC, EK, K4
model)
3) Remove the clip (A) from upper side of air clean-
er case.
4) Pull the air cleaner case (rear) to rearward of the
vehicle, and then remove the air cleaner element.
Be careful that the power steering hose is secured
to the under side of air cleaner case (rear).
B: INSTALLATION
Install in the reverse order of removal.
Fasten the air cleaner case (rear) with a clip after
inserting the lower tab of the case.
C: INSPECTION
Replace if excessively damaged or dirty.
IN-00203
IN-00204
IN-00254
(A)
IN-00207
