FU(H4SO 2.0)-7
FUEL INJECTION (FUEL SYSTEMS)
General Description
(1) Fuel tank (12) Fuel sub level sensor upper plate (22) Retainer
(2) Fuel tank band RH (13) Fuel sub level sensor gasket (23) Heat shield cover
(3) Fuel tank band LH (14) Fuel filler hose (24) Fuel tank protector RH (Front)
(4) Delivery tube (15) Clamp (25) Fuel tank protector LH (Front)
(5) Return tube (16) Vent hose
(6) Jet pump tube (17) Clip Tightening torque: N
⋅
m (kgf-m, ft-lb)
(7) Fuel pump assembly (18) Fuel tank protector RH (Rear) T1: 4.4 (0.45, 3.3)
(8) Fuel pump upper plate (19) Fuel tank protector LH (Rear) T2: 9.0 (0.92, 6.6)
(9) Fuel pump gasket (20) Stopper RH T3: 17.5 (1.78, 12.9)
(10) Fuel level sensor (21) Stopper LH T4: 33 (3.4, 25)
(11) Fuel sub level sensor
