6.2. MAHLE ebikemotion Parts and Descriptions — EU
No. Name A18 SKU# Qty
Parts included in the frameset
1 Rear Wheel Road – EU (for 314A)
-OR-
Rear Wheel Gravel – EU (for 314B)
81187
-OR-
81189
1
2 Front Wheel Road – EU (for 314A)
-OR-
Front Wheel Gravel – EU (for 314B)
81186
-OR-
81188
1
3 KIT X35 – C – One Flat – EU 81216 1
3.1 X35 B1-C Battery - 6.9A 81218 1
3.2 Drive unit-M1-C – EU (*Already Included in the Rear Wheel) 81224 1
3.3 Torque Washer Nut 81229 2
3.4 Motor Lock Nut 81228 2
3.5 Shield M1 81230 1
3.6 Freewheel Nut 81226 1
3.7 One Remote 81231 1
3.8 Charging Point – ROUND CONN. 81220 1
3.9 PAS Sensor B – ROUND CONN. 81232 1
3.10 Magnet Lock Nut 81227 1
3.11 Charger-C (Without Wire) 81219 1
3.12 Charger Wire for Europe 81221 1
3.13 Charger Wire for United Kingdom 81222 1
Optional parts that can be ordered separately
- External Battery SP1 + Holder 81223 1
- Ligth Wire – eBikeMotion X35 N/A 1
- PCAN USB Adaptor 81282 1
- Diagnosis Wire 81283 1
