24
SUBITO 314A / 314B: ASSEMBLY GUIDE
12.1 Cable and housing routing – Mechanical shifting
1. All cables must be routed above the battery.
2. The rear brake housing will be above the BB once installed.
3. Both derailleur housing will be under the BB once installed.
4. All housing can be covered by a foam liner (SKU: 80811).
brake housing
derailleur cable/housing
Front
Rear
