23
11.6 Iwoc One Installation
Light Connector
Light Connector
1. Guide the iWok one remote
connector from the battery
through the top tube hole.
2. Connect the iWok one remote
connector to the matching
connector on the battery.
3. Push the cable in the top tube
in the seat tube direction.
4. Insert the top tube button cap
with the button cap clip first,
and align the hole with the rivet.
5. Push the light cable in
the top tube.
