SUBITO 314A / 314B: ASSEMBLY GUIDE
15.2 Cable and housing routing – Electronic wireless routing
Rear Derailleur:
1. Install the plug grommet (SKU: 80804) in the seat stay hole.
Rear Brake:
1. Insert housing from rear hole on the
chainstay.
2. Guide the housing over the battery
through the BB hole.
3. Exit the housing through the side
guide hole.
4. Insert the rear brake oblong cable guide
(SKU: 80551) into the chainstay hole.
80551
80804
