SUBITO ARGON 18 - BB Cover Installation; Install Bottom Bracket; Install and Torque BB Cap

45
17.4 BB Cover installation
1. Install the bottom bracket using a bottom bracket press.
2. Push the cable into the opening. Make sure the motor cable has enough range
of movement to be able to remove the wheel without removing the BB cap.
3. Install the BB cap (SKU: 81241), torque the M4 x 10mm button head cap screw
(SKU: 81251) to 2Nm, do not apply grease.
81251
M4 x 10mm
81241
4
4Nm
4
3Nm
3Nm
2
2Nm
3
3Nm
5
9.5Nm
4
5Nm
2
HT
8
12Nm
8
35Nm
2.5
2Nm
2
0.5-1Nm
40Nm
4Nm
T25
T25
