Section 7
ILLUSTRATIONS AND PARTS LIST
41
7.3 ENGINE, COMPRES SOR A ND PARTS --- J OHN DEERE --- 18 5 MODELS (con tinu ed)
key description: engine, compressor & parts part
number (continued) number quantity
29 washer, lock m8 838808---200 6
30 capscrew, hex 8.8 m8 x 55mm 828008---055 6
31 capscrew, hex gr5 5/8---11 x 1---1/2” pltd 829110---150 4
32 washer, lock reg 5/8” pltd 837810---156 4
33 capscrew, ferry hd 3/8 x 1 1/2” plt 867306---150 8
34 washer, sprlock metric m10 pltd 838810---220 12
35 nut,hex locking 5/8 pltd 825510---329 4
36 washer, pl b r 5/8” pltd 838210---112 4
37 capscrew, hex gr5 5/8---11 x 3---1/2pltd 829110---350 4
38 washer, lock metric m12 838812---250 14
39 capscrew, hex 8.8 m12 x 30mm 828012---030 14
40 nut,hex locking pltd 1/4---20 825504---145 2
41 elbow, check valve 1/4” x 1/8p 02250058---275 1
42 capscrew, ferry head 1/4---20 x 1---1/4” pl 867304---125 2
43 tee, reducing 1---1/2x1/2x1---1/2” pltd 867506---026 1
44 washer, pl b r 3/8” pltd 838206---071 12
45 nipple,pipe 3/4 x cl sc 80 pltd 866412---000 1
46 nipple,pipe 1---1/2 x cl sc 80 pltd 866424---000 1
47 capscrew, ferry hd 3/8---16 x 1 1/4 867306---125 7
48 nipple,pipe 1---1/2 x 6.0 sc 80 pltd 866324---060 1
49 elbow, pipe 1---1/2 pltd 866215---060 1
50 elbow, pipe 3/4 pltd 866215---030 1
51 capscrew, hx 8.8 m10 x 35mm 828010---035 12
description: speed cylinder --- ITEM 20
1 rod 250011---590 1
2 cylinder, speed 250021---405 1
3 joint, ball 250011---597 1
4 elbow 250018---429 1
5 joint, ball 250011---578 1
6 nut,hex jam rh unfin 1/4” 824604---164 2
7 nut,hex jam lh unfin 1/4” 824704---164 1
8 spring 250022---782 1
9 washer, pl b r 1/4” 837204---071 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
