Figure 2-5: Standard pneumatic control system
1. Air outlet 5. Blowdown valve
2. Unload solenoid valve 6. Minimum pressure/check valve
3. Pressure regulator 7. Separator/sump tank
4. Air inlet 8. Sequencing solenoid valve
