3000PB, 3700B, 4500B, 3000PVB, 3700VB, 4500VB User Manual 3: Specifications
02250216-786 R01
Subject to EAR, ECCN EAR99 and related export control restrictions. 29
3.9 Identification, water-cooled
Machine weights
Model
Main motor
hp Motor type Weight
cfm
cooling air
3000PB 40
ODP 1965 LBS/891 kg 730
TEFC 1989 LBS/902 kg 730
3700B 50
ODP 1990 LBS/903 kg 730
TEFC 2030 LBS/921 kg 730
4500B 60
ODP 2276 LBS/1032 kg 730
TEFC 2354 LBS/1068 kg 730
Drawing notes
1
ALLOW 4.00 FEET [1.25 METERS] MINIMUM CLEARANCE
AROUND MACHINE FOR ACCESS AND FREE CIRCULATION
OF AIR.
2
A FOUNDATION OR MOUNTING CAPABLE OF SUPPORTING
THE WEIGHT OF PACKAGE, AND RIGID ENOUGH TO
MAINTAIN THE COMPRESSOR FRAME LEVEL IS REQUIRED.
THE COMPRESSOR FRAME MUST BE LEVELLED AND
SECURED BETWEEN THE FRAME AND THE FOUNDATION. NO
PIPING LOADS ARE PERMITTED AT EXTERNAL
CONNECTIONS.
3 ALL DIMENSIONS ARE ± .50" [12.7MM].
4
RECOMMENDED INCOMING CUSTOMER POWER SUPPLY IS
SHOWN ON DRAWING.
5
ALL DIMENSIONS SHOWN IN INCHES WITH MILLIMETER
DIMENSIONS IN PARENTHESES.
