Section 2
DESCRIPTION
8
FLUID
FILTER
THERMAL
VALVE
MINIMUM PRESSURE/
CHECK VALVE
SEPARATOR
ELEMENT
MOISTURE
SEPARATOR
SUMP TANK
FLUID
AIR
FLUID/AIR
AFTERCOOLER
FLUID
COOLER
WATER
CONTROL
VALVE
Figure 2-4 Compressor Fluid Cooling/Lubrication and Discharge System- Water-cooled
