Section 8
ILLUSTRATIONS AND PARTS LIST
52
8.2 RECOMMENDED SPARE PARTS LIST (CONTINUED)
DESCRIPTION KIT NUMBER QTY
kit, repair for shaft seal 02250049-258 1
kit, repair for 1-1/2” combination separator/trap 02250144-635 02250144-735 1
kit, repair for 1” combination separator/trap 02250144-636 02250144-736 1
kit, replacement for Supervisor controller 02250083-301 02250106-360 1
replacement element(s) for drive coupling (II) -
kit, repair for v-type strainer 241771 241772 1
manual, Sequencing & Protocol (III) 02250139-197 1
fluid, SRF 1/4000 (5 gallons) 250019-662 (IV)
lubricant, Sullube (std.) (5 gallons) 250022-669 (IV)
lubricant, 24 KT (5 gallons) 046850-001 (IV)
(II) For maintenance on coupling element for your machine, consult the following table:
COUPLING HUB NO.
HP MODEL FREQUENCY MOTOR FRAME MOTOR COMPRESSOR ELEMENT
25 ALL ALL ALL 045671 045673 045672
30 ALL 60Hz ALL 045671 045673 045672
30 ALL 50Hz ALL 250030-700 02250077-075 250004-638
40 ALL 60Hz ALL 250004-640 250004-639 250004-638
40 L,H,HH 50Hz ODP 045671 045673 045672
40 L,H,HH 50Hz TEFC 250004-640 250004-639 250004-638
40 XH 50Hz ALL 250004-640 250004-639 250004-638
(III) This document is required to program your personal computer to communicate with the Supervisor II
panel.
(IV) For proper amount of fluid fill, please consult Lubrication Guide in Section 3, Specifications.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
