Section 8
ILLUSTRATIONS AND PARTS LIST
55
8.3 MOTOR, COMPRESSOR, FRAME AND PARTS
key part
number description number quantity
1 motor, 25/30/40hp tefc & 40hp odp - 1
2 compressor & part, dxx102147e (I) -1
3 element, cplg type l-190 (II) -1
4 coupling l-190 1-1/2 x 3/8 (II) -1
5 hub, coupling l-190 1-7/8 x 1/2 (II) -1
6 support, bracket start box ls-10 l.h. 02250103-969 1
7 support, bracket start box ls-10 r.h. 02250104-194 1
8 support, unit ls10 02250139-286 1
9 frame, assy ls10-25/30/40hp 02250139-868 1
10 grommet, rubber 02250141-414 6
11 plate, mtg frame ext tefc 02250143-521 1
12 plate, motor/compr adapt cover 225980 1
13 adapter, motor compr 10/40 231977 1
14 adapter, sae 5 dxx10 gi ma 250009-542 1
15 adapter, unit to mtr-compr 250038-448 1
16 grille, cplg guard compr/mtr 250040-319 2
17 nut, hex pltd 3/8-16 825206-337 7
18 nut, hex pltd 1/2-13 825208-448 2
19 nut, hex f pltd 5/16-18 825305-283 8
20 capscr, hex 8.8 m12 x 25mm 828012-025 2
21 capscr, hex gr5 3/8-16 x 1 1/4 829106-125 7
22 capscr, hex gr5 3/8-16 x 1 3/4 829106-175 7
23 capscr, hex gr5 1/2-13 x 1 1/4 829108-125 2
24 capscr, hex gr5 1/2-13 x 2 829108-200 2
25 capscr, hex gr5 5/8-11 x 1 1/2 829110-150 4
(Continued on page 57)
(I) There is an exchange program whereby a remanufactured compressor unit can be obtained from Sullair
distributors or the factory at less cost than the owner could repair the unit. For information regarding
the unit exchange program, contact your nearest Sullair representative or the Sullair Corporation.
The shaft seal is not considered part of the compressor unit in regard to the two year warranty. The nor-
mal Sullair parts warranty applies. For shaft seal repairs, order shaft seal repair kit no. 02250049-258.
(II) For maintenance on drive coupling, consult Section 8.2, Recommended Spare Parts List.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
To Next Page
