Section 8
ILLUSTRATIONS AND PARTS LIST
59
8.4 COOLER ASSEMBLY
key part
number description number quantity
1 fan,18ӯ blower ls-10 (I) -1
2 set scew, 3/8-16unc 02250122-608 2
3 key,square rounded both ends ls10- 02250123-415 1
4 cooler, comb air/oil 02250140-334 1
5 shroud, fan ls10 std 02250140-412 1
6 guard,fan ls10-25/30/40hp std 02250140-421 2
7 angle,shroud fan base 02250140-442 1
8 venturi,fan 18.5” dia 02250140-519 1
9 hub, fan drive (I) 02250143-405 1
10 weatherstrip, 3/16 x 3/8 ft - 250022-436 8
11 screw, hex ser washer 5/16-18 x 3/4 829705-075 18
12 washer, spr lock reg pltd 3/8 837806-094 4
13 capscrew, ferry head hd pltd 3/8-16 x 1 867306-100 4
14 insert, nut 5/16-18 .027-.150 876205-150 10
(I) For a breakdown of fan assembly, consult the following table:
HP MODEL FREQUENCY MOTOR FRAME FAN FAN HUB
25 ALL 60Hz ALL 02250141-472 02250143-408
30 ALL 60Hz ALL 02250141-472 02250143-408
40 ALL 60Hz ALL 249012 02250142-405
25 ALL 50Hz ALL 02250141-470 02250143-408
30 ALL 50Hz ALL 02250141-470 02250143-408
40 L,H,HH 50Hz ODP 02250141-472 02250143-408
40 L,H,HH 50Hz TEFC 02250141-472 02250143-407
40 XH 50Hz ALL 249012 02250143-405
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
