Section 8
ILLUSTRATIONS AND PARTS LIST
63
8.6 AIR PIPING- AIR-COOLED
key part
number description number quantity
1 support, water sep ls10 02250141-448 2
2 tube, cooler to moist sep 1-1/4” 02250141-664 2
3 tube, 1-1/4”-mpv to clr a/c 02250142-982 2
4 separator, water d-h 1-1/2” fnpt 1/4” drn (I) 02250144-635 2
5 separator, water d-h 1” npt 1/4”drn (II) 02250144-636 2
6 connector, 1/4”tube x 1/4”npt 250018-428 4
7 elbow, 1/4” tube x 1/4” npt 250018-430 4
8 connector, tube-m 1 1/4 x 1 1/4 810220-125 2
9 elbow, tube 90 deg m 1 1/4 x 1 1/4 810520-125 2
10 elbow, tube 45m 1 1/4 x 1 1/4 811720-125 2
11 connector, tube str thd 1 1/4 x 1 5/8 811820-163 2
12 screw, hex ser washer 5/16-18 x 3/4 829705-075 4
13 nipple, pipe-xs plt 1 x cl 866416-000 2
14 nipple, pipe-xs plt 1 x 3 1/2 866416-035 2
15 nipple, pipe-xs plt 1 1/2 x cl 866424-000 4
16 tee, reducing pltd 1 x 1/2 x 1 867504-024 2
17 tee, reducing pltd 1 1/2 x 1/2 x 1 1/2 867506-026 2
18 bushing, red hex pltd 1/2 x 1/4 868902-010 2
19 bushing, red hex pltd 1 1/2 x 1 868906-040 2
(I) For maintenance on water separator no. 02250144-635, order repair kit no. 02250144-735.
(II) For maintenance on water separator no. 02250144-636, order repair kit no. 02250144-736.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
