Section 8
ILLUSTRATIONS AND PARTS LIST
67
8.8 FLUID PIPING- 25, 30 & 40HP/ 18, 22 & 30KW TEFC
key part
number description number quantity
1 valve, thermal 185 deg f es11(I) 02250078-204 1
•valve, thermal 195 deg f es11 (II) 02250092-081 1
2 connector, sae x orfs 0.75” 02250099-765 3
3 elbow, 90 sae x orfs .75” 02250099-766 3
4 filter, fluid 1-5/8 sae (III) 02250136-535 1
5 housing, thrm vlv 02250140-340 1
6 hose, medium pressure orfs 1”x 53” 02250141-104 1
7 hose, medium pressure orfs 1”x 76” 02250141-105 1
8 hose, medium pressure orfs 1”x 21” 02250141-106 1
9 clamp, tubing 1-1/8” dia 250025-636 3
10 nut, hex f pltd 5/16-18 825305-283 3
11 o-ring, viton 13/16 x 1/8” 826502-211 2
12 o-ring, viton 1 5/16 x 1/8” 826502-219 1
13 capscrew, socket hd 3/8-16 x 3 1/4 828306-325 2
14 screw, hex ser washer 1/4-20 x 1/2 829704-050 2
15 screw, hex ser washer 5/16-18 x 3/4 829705-075 3
16 reducer, str thrd viton 1 1/4 x 3/4 870020-012 2
(I) For maintenance on (185ºF) thermal valve no. 02250078-204, order repair kit no. 02250144-326.
(II) For maintenance on (195ºF) thermal valve no. 02250092-081, order repair kit no. 02250144-327. NOTE:
195ºF thermal valve is used on “HH”, “XH” and 24KT (“L” and “H”) machines.
(III) For maintenance on fluid filter no. 02250136-535, order replacement element no. 250025-525.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
To Next Page
