Sullair LS-100L User Manual

Section 8
ILLUSTRATIONS AND PARTS LIST
73
8.11 COOLING AND LUBRICATION SYSTEM- COOLERS (WATER-COOLED)
key part
number description number quantity
1 cooler, heat exchanger 02250110-238 1
2 cover, assy motor shaft tefc 02250110-925 1
3 support, oil cooler ls10 w/c 02250141-143 1
4 support, bracket shaft cover odp ls10wclf 02250141-634 1
5 clamp,exhaust 3-1/2” 040284 2
6 clamp, exhaust 4-1/2” 041983 2
7 aftercooler, heat exchanger 3 x 24 043096 1
8 nut, hex f pltd 5/16-18 825305-283 6
9 screw, hex ser washer 5/16-18 x 3/4 829705-075 6
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
