Section 9
ILLUSTRATIONS AND PARTS LIST
111
9.24 CANOPY- WATER-COOLED (40-75HP/ 37-56KW)
key part
number description number quantity
1 motor, .25HP (230, 460V) 250000-031 1
2 grip, cord 1/2" 250021-321 1
3 wire, neoprene #16-4 850604-016 8
4 nut, hex flanged 5/16" 825305-283 4
5 screw, hex serrated washer 5/16" x 3/4" 829705-075 4
6 guard, exhaust fan 410179 1
7 nut, hex flange 5/16" 825305-283 4
8 washer, plain 5/16" 838205-071 8
9 fan, vent 18" 410358 1
10 panel, access roof 250017-309 2
11 panel, fiberglass roof 250020-012 2
12 panel, access roof 250017-308 1
13 screw, hex serrated washer 5/16" x 3/4" 829705-075 4
14 guard, fan 20" 241137 1
15 panel, corner - left hand 02250142-669 2
16 panel, enclosure end 250018-647 2
17 panel, corner - right hand 250018-609 2
18 panel, access side special 250034-296 1
19 panel, front side 02250099-223 1
20 panel, access side 250017-310 4
21 latch, adjustable trigger lock 049764 6
22 panel, fiberglass door 250020-015 12
23 panel, access side 250034-297 1
24 panel, back side 250017-312 1
25 decal, black 12” x 43.5” 02250144-131 1
26 decal, black 12” x 14” 02250144-130 1
27 decal, warning auto start 041065 1
28 decal, warning auto start 250017-903 1
29 sign, warning sever fan 049855 1
30 sign, warning sever fan 049965 1
31 decal, rotation 250021-564 1
32 decal, LS-120 02250144-126 1
•decal, LS-160 (not shown) 02250144-128 1
33 decal, ISO 9001 02250057-624 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
