Section 3
SPECIFICATIONS
15
3.1 TABLE OF SPECIFICATIONS
LS-12 SERIES 50 Hz
MODEL (I) KW LENGTH WIDTH HEIGHT(II) WEIGHT KG
MM MM MM OPEN/ENCLOSED
H, HH, XH 37 1829 1219 1524 1043/1220
HH, XH 45 1829 1219 1524 1134/1311
LS-12 SERIES 60 Hz
MODEL (I) HP LENGTH WIDTH HEIGHT(II) WEIGHT LB
IN IN IN OPEN/ENCLOSED
L, H, HH 40 72 48 60 2270/2660
L, H, HH, XH 50 72 48 60 23002690
H, HH, XH 60 72 48 60 2500/2890
LS-16 SERIES 50 Hz
MODEL (I) KW LENGTH WIDTH HEIGHT(II) WEIGHT KG
MM MM MM OPEN/ENCLOSED
H, HH, XH 45 1829 1219 1588 1220/1442
H, HH, XH 56 1829 1219 1588 1233/1456
L, H 75 1829 1219 1588 1243/1546
LS-16 SERIES 60 Hz
MODEL (I) HP LENGTH WIDTH HEIGHT(II) WEIGHT LB
IN IN IN OPEN/ENCLOSED
L, H, HH 60 72 48 60 2690/3180
L, H, HH, XH 75 72 48 60 2720/3210
L, H 100 72 48 59.4 2740/3410
For latest sound test data, consult Sullair Factory.
(I) Includes standard and 24KT. Rated pressure designations appearing after model number are as follows:
“L”- 100 psig /6.9 bar “H”- 125 psig/8.6 bar
“HH”- 150 psig/10.3 bar “XH”- 175 psig/12 bar
Maximum pressure is rated pressure and 10 psig (0.7 bar).
(II) (Except for 16-100 60Hz models) Height listed is for models without enclosure. Height for enclosed models is 1588 mm/
62.5 in. Add an additional length of 102 mm/ 4 in. (non-enclosed models) or 229 mm/ 9 in. (enclosed models) for servic-
ing the separator.
COMPRESSOR: STANDARD MODELS
Type: Rotary Screw
Standard Operating Pressure (III): 100 psig (6.9 bar) (L) 150 psig (10.3 bar) (HH)
125 psig (8.6 bar) (H) 175 psig (12 bar) (XH)
Bearing Type: Anti-Friction
Ambient Temperature (Max.) (IV): 105°F (41°C)
Cooling: Pressurized Fluid
Compressor Fluid: Sullair Sullube
Sump Capacity: 8.0 U.S. gallons (30 liters)
Control: Electro-Pneumatic
Supervisor Controller (optional)
(III) Special compressors are available for operation at higher pressures.
(IV) Special compressors are available for operation in higher ambient temperature.
