Section 9
ILLUSTRATIONS AND PARTS LIST
59
9.7 AIR INLET SYSTEM LS-160 WATER-COOLED
key part
number description number quantity
1 support, air filter 02250106-704 1
2 screw, hex ser washer 3/8" x 1" 829706-100 2
3 capscrew, hex GR5 3/8"-16 x 2 1/2" 829106-250 2
4 washer, reg 3/8" 838206-071 2
5A filter, air inlet (60& 75HP/ 45 & 56KW) (I) 02250091-634 1
5B filter, air inlet (100HP/ 75KW) (II) 02250059-096 1
6 band, mounting 12" 040081 1
7 clamp, hose 6" 408153 3
8 hose, flexible 5" 02250093-920 1
9 tube, air inlet w/ connectors 02250126-730 1
10 connector, tube-M 1/4" x 1/8" 250018-427 1
11 plug, pipe 1/8" 807800-005 1
12 elbow, 37ºfl 90ºm 1/2” x 1/4” 860208-025 1
13 elbow, rubber 90º 5" 02250061-835 1
14 valve, air inlet 4" (III) 02250143-377 1
15 capscrew, hex GR5 1/2"-13 x 1 1/2" 829108-150 4
16 washer, springlock 1/2" 837808-125 4
17 connector, tube-M 1/4"T x 1/4"P 250018-428 1
18 gasket, 5 1/4" OD (IV) 040708 1
19 washer, springlock 3/8" 837806-094 2
20 nut, hex 3/8" 825206-337 2
21 orifice, .25 x 1/4”m x 1/4”f 02250143-403 1
(I) For maintenance on air filter no. 02250091-634, order replacement element no. 250018-652.
(II) For maintenance on air filter no. 02250059-096, order primary replacement element no. 02250046-012,
and secondary replacement element no. 02250046-013.
(III) For maintenance on air inlet valve no. 02250143-377, order repair kit no. 250029-249.
(IV) For maintenance on air inlet, coat gasket no. 040708 with Loctite® 5900 or equivalent type of sealing
agent before reassembly.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
