Section 9
ILLUSTRATIONS AND PARTS LIST
63
9.8 COOLING AND LUBRICATION SYSTEM (AIR-COOLED) (CONTINUED)
key part
number description number quantity
22 screw, hex ser washer 5/16" x 1/2" 829705-050 2
23 washer, springlock #10 837802-047 2
24 nut, hex plated #8 x 32 825201-130 2
25 decal, warning mixing fluids 02250110-891 1
26 decal, warning compressor fluid fill cap 049685 1
27 decal, Sullube (III) 02250069-389 1
28 reducer, 1 7/8" x 1 5/8" (100HP/ 75KW) 870024-020 2
(III) Sullube is the standard fill for LS-120 and LS-160 air compressors. If your compressor has an optional
fill, consult Section 9.26, Decal Group (key numbers 20A-20D) for matching fluid decal part number.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
To Next Page
