Section 9
ILLUSTRATIONS AND PARTS LIST
79
9.12 COMPRESSOR DISCHARGE SYSTEM (AIR-COOLED)
key part
number description number quantity
1 cooler, fluid aftercooler (LS-120) 02250142-507 1
•cooler, fluid aftercooler (LS-160 60-75HP/45-56KW) 02250096-706 1
•cooler, fluid aftercooler (100HP/ 75KW) 02250053-915 1
2 nipple, pipe 1 1/2" x close 866424-000 1
3 coupling, reducing 2" x 1 1/2" 879416-012 1
4 connector, tube-M 1 1/2" x 1 1/2" (LS-120) 810224-150 1
•connector, tube-M 2" x 2" (LS-160) 810232-200 1
5 tube, MPV to cooler (LS-160) 02250142-608 1
•tube, MPV to cooler (LS-120) 02250098-477 1
6 elbow, tube 1 1/2" (LS-120) 811624-188 1
•elbow, tube 2" (LS-160) 811632-250 1
7 elbow, tube-M 1/4" x 1/8" 250018-429 1
8 valve, minimum pressure (LS-120) (I) 02250097-598 1
•valve, minimum pressure (LS-160) (II) 02250109-817 1
9 capscrew, hex GR8 5/8"-11 x 2" 828210-200 8
10 washer, springlock 5/8" 837510-156 8
11 elbow, tube-M 1/4" x 1/4" 250018-430 4
12 adapter, SAE 1 7/8" x 1 7/8" (LS-120) 02250055-014 1
•adapter, SAE 2 1/2" x 2" (LS-160) 02250110-661 1
13 connector, flex 1/4" x 1/4" 020169 2
14 tubing, 1/4" stainless steel 841215-004 14.5
15 connector, tube male bulkhead, 1/4" 02250101-490 1
16 bracket, mounting support 02250101-192 1
17 connector, tube-M str thd 1/4" x 7/16" 811804-044 1
18 sight glass 046559 2
19 orifice 02250125-774 2
20 elbow, 1/4"F x 1/4"M 860704-025 1
21 tee, M 1/4" x 1/4" x 1/4" 869825-025 1
22 connector, tube-F 1/4" x 1/4" 810104-025 1
(Continued on page 81)
(I) For maintenance on minimum pressure valve no. 02250097-598, order repair kit no. 02250110-727, cap
kit no. 02250046-396, o-ring kit no. 02250048-363, and piston kit no. 02250051-337.
(II) For maintenance on minimum pressure valve no. 02250109-817, order repair kit no. 250018-456, cap kit
no. 02250044-355, o-ring kit no. 02250048-365, and piston kit no. 02250051-336.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
