Section 9
ILLUSTRATIONS AND PARTS LIST
83
9.12 COMPRESSOR DISCHARGE SYSTEM (AIR-COOLED) (CONTINUED)
key part
number description number quantity
46 adapter, discharge 02250097-526 1
47 capscrew, ferry hd 3/8"-16 x 2 1/4" 828406-225 4
48 elbow, tube-M 1/4" x 1/4" SS 250211-005 1
49 connector, tube-SAE 1/4" x 7/16" 870906-025 1
50 flange, split 2" kit 02250099-415 1
•o-ring 826502-228 1
51 tube, flexible 02250110-538 1
52 flange, split 2 1/2" kit 02250099-416 1
•o-ring 826502-232 1
53 valve, relief 3/4" (50-75HP/ 37-56KW) 02250110-968 1
•valve, relief 3/4" (100HP/ 75KW) 02250097-349 1
54 elbow, tube-M 1/4" x 1/8" SS 250211-013 1
55 screw, hex ser washer 5/16"-18 x 1" 829705-100 4
56 nut, hex flange 5/16"-18 825305-283 4
57 support, water separator 02250142-589 2
58 nipple, pipe 1 1/2" x 3 1/2" 866324-035 1
59 U-bolt, 1/4" x 1 1/2" pipe 868304-150 1
60 separator, moisture (40, 50HP)(VII) 02250144-635 1
•separator, moisture (60-75HP/ 45-75KW)(VIII) 02250144-633 1
•separator, moisture (100HP/ 75KW)(IX) 02250144-632 1
61 decal, water drain 250022-810 1
62 tee, reducing 1 1/2" x 1 1/2" x 1/2" 867506-062 1
63 bushing, reducing hex
64 elbow, tube
(VII) For maintenance on moisture separator no. 02250144-635, order auto-drain repair kit no. 02250144-
735.
(VIII) For maintenance on moisture separator no. 02250144-633, order auto-drain repair kit no. 02250144-
732.
(IX) For maintenance on moisture separator no. 0225144-632, order auto-drain repair kit no. 02250144-732.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
