Section 8
ILLUSTRATIONS AND PARTS LIST
59
8.6 FLUID COOLING SYSTEM- 100-125HP AIR-COOLED
key part
number description number quantity
1 bushing, split taper p1 1-5/8”brn 02250043-645 1
2 motor, 7.5hp 230/460/60 6p aope 02250128-791 1
3 cooler, aftclr 500# 2”npt stl 16T 02250138-182 1
4 cooler, oil 500# 1 7/8 sae stl LS16T 02250138-183 1
5 plate, adapter clrpk LS16T-100/125a 02250138-221 1
6 panel, venturi 36” LS16T-100/125a 02250139-054 1
7 fan, 36” cw rotation 250022-605 1
8 support, fan mtr 20/12-200/300 250041-048 1
9 adapter, venturi/aftclr-20/12 250041-106 1
10 support, clr assy-20/12 250041-116 1
11 support, clr assy-20/12 250041-119 2
12 guard, fan 20/12-500/750 cfm 250042-676 1
13 nut, hex pltd 1/2-13 825208-448 6
14 nut, hex f pltd 5/16-18 825305-283 28
15 nut, hex f pltd 3/8-16 825306-347 14
16 nut, hex locking 3/8-16 825506-198 12
17 capscr, hex gr5 5/16-18 x 3/4 829105-075 8
18 capscr, hex gr5 3/8-16 x 1 829106-100 8
19 capscr, hex gr5 3/8-16 x 1 1/2 829106-150 4
20 capscr, hex gr5 1/2-13 x 1 1/2 829108-150 6
21 screw, hex ser washer 5/16-18 x 3/4 829705-075 42
22 screw, hex ser washer 3/8-16 x 3/4 829706-075 21
23 washer, spr lock reg pltd 1/4 837804-062 1
24 washer, spr lock reg pltd 5/16 837805-078 8
25 washer, spr lock reg pltd 1/2 837808-125 6
26 washer, pl-b reg pltd 5/16 838205-071 8
27 washer, pl-b reg pltd 3/8 838206-071 8
28 washer, pl-b reg pltd 1/2 838208-112 8
29 nut, retainer 5/16-18 .092 861405-092 22
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
