Section 8
ILLUSTRATIONS AND PARTS LIST
73
8.11 FLUID PIPING SYSTEM- 150-200HP WATER-COOLED
key part
number description number quantity
1 adapter, sae 1 7/8-12 x 1 7/8-12 02250055-014 1
2 seal, u-cup therm vlv (I) 02250101-372 1
3 valve, oil stop (II) 02250113-668 1
4 filter, 1 7/8-12 sae coreless (III) 02250121-658 1
5 housing, therm vlv 1 7/8”-12 conn w/ ext 02250127-119 1
6 tube, thermal vlv/clr LS16T 1.50” 02250135-181 1
7 tube, clr/thrm vlv LS16T 1.50” 02250135-183 1
8 tube, thermal vlv/fltr ls16t 1.50” 02250135-185 1
9 support, oil filter - LS16T 02250135-190 1
10 tube, fltr/osv LS16T 1.5” 02250138-945 1
11 element, thermal vlv 220deg f (I) 250001-349 1
12 elbow, tube 90 deg m 1 1/2 x 1 1/2 810524-150 2
13 elbow, tube str thrd 1 1/2 x 1 7/8 811624-188 3
14 connector, tube str thd 1 1/2 x 1 7/8 811824-188 3
15 nut, hex pltd 3/8-16 825206-337 2
16 o-ring, viton 2 1/2 x 3/32” (I) 826502-144 1
17 capscr, hex gr5 3/8-16 x 1 1/4 829106-125 2
18 screw, hex ser washer 5/16-18 x 3/4 829705-075 4
19 washer, spr lock reg pltd 3/8 837806-094 2
20 washer, pl-b reg pltd 3/8 838206-071 4
21 bushing, red pltd 2 x 1 1/2 867108-060 2
22 capscrew, ferry head hd pltd 3/8-16 x 1 867306-100 4
23 elbow, tube 90 deg m 1/4 x 1/8 ss 877004-012 1
(I) This part is required for maintenance on thermal valve.
(II) For maintenance on fluid stop valve no. 02250113-668, order repair kit no. 02250116-697.
(III) For maintenance on fluid filter no. 02250121-658, order repair kit no. 0250121-657.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
