Section 8
ILLUSTRATIONS AND PARTS LIST
83
8.13 CONTROL/START SYSTEM (CONTINUED)
key part
number description number quantity
28 washer, spr lock reg pltd 3/8 837806-094 4
29 washer, spr lock reg pltd 1/2 837808-125 4
30 washer, pl-b reg pltd 3/8 838206-071 4
31 washer, pl-b reg pltd 1/2 838208-112 4
32 bulkhead, pipe 1/4” npt 841500-004 4
33 locknut, conduit 1/2 847200-050 5
34 bushing, conduit plastic 1/2 848815-050 3
35 bushing, red pltd 1/2 x 1/4 867102-010 1
36 tee,male pipe stainless 1/4 869925-025 1
37 elbow, pipe 90 deg 1/4” 300# ss 876630-010 2
38 tee, pipe 300# 1/4 ss 876730-010 1
39 connector, tube-m 1/4 x 1/8 ss 876804-012 2
40 connector, tube-m 1/4 x 1/4 ss 876804-025 5
41 cross, pipe 1/4” 300# ss 876930-010 1
42 elbow, tube 90 deg m 1/4 x 1/8 ss 877004-012 2
43 elbow, tube 90 deg m 1/4 x 1/4 ss 877004-025 4
44 elbow, tube 90 deg m 1/2 x 1/2 ss 877008-050 1
45 starter, nc n12 (V) -1
(V) Starters may vary with machine specifications. Consult factory with serial number to determine correct
starter number.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
