Section 8
ILLUSTRATIONS AND PARTS LIST
85
8.14 CONTROL PANEL
key part
number description number quantity
1 gasket, panel Supervisor II 02250048-822 1
2 panel, instrument Supervisor II 02250054-853 1
3 panel, cover Supervisor II 02250054-854 1
4 nameplate, Sullair serial number 02250059-318 1
5 decal, LS Super 2 front (I) (II) 02250116-245 1
6 harness, wire sii dlx std pwr 02250105-438 1
7 harness, wire s2 dlx ctl 02250105-439 1
8 block, contact 1nc 250027-125 2
9 switch, per red push/pull e22 250028-588 1
10 control, Supervisor II deluxe (II) 250042-023 1
11 nut, hex f pltd 5/16-18 825305-283 4
12 nut, hex metric m4 x .7 825904-070 8
13 screw, hex ser washer 5/16-18 x 3/4 829705-075 4
14 screw, tc-f pan #8-32 x 1/2 835601-050 8
15 washer, lock ext tooth #8 838401-023 8
16 washer, spr lock-metric pltd m4 838804-090 8
17 rivet, pop 1/8 x 3/8 843102-038 4
(I) For detail of Supervisor II panel decal, see Figure 2-6, Supervisor II Panel in Section 2, Description.
(II) Use replacement kit no. 02250143-166 for items 5 and 10 assembled with programming.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
