Section 9
ILLUSTRATIONS AND PARTS LIST
69
9.12 DISCHARGE SYSTEM
key part
number description number quantity
1 adapter, filler 020044 1
2 connector, flex 1/4t x 1/4p 020169 2
3 flange, kit sae splt 2.5” - viton 02250099-416 1
4 connector, tube male bhd 1/4 x sae 02250101-490 1
5 filter, asembly genisis filter (I) 02250117-782 2
6 valve, ball 3/4” npt apollo 02250117-792 1
7 adapter, discharge vlv m85 ddh204 hp 02250124-030 1
8 orifice, plug brass 1/8”npt x 1/32” 02250125-774 1
9 orifice, plug brass 1/8”npt x 1/16” 02250125-775 1
10 sightglass, orf block sae 02250126-129 2
11 sub-assembly, vlv assy m85 x 2.5 4bsf disch (II) 02250126-832 1
12 support, oil return/sightglass line 02250128-598 1
13 nut, hex m85-2 6h 02250130-997 1
14 valve, relief 1” npt 400psi 02250137-688 1
15 pipe assembly, disch ls20t o-ring 02250148-030 1
16 plug, o-ring boss sae 1 1/4 040029 1
17 glass, oil level sight 1-1/2” 040279 1
18 valve, check 1/2” 042694 1
19 valve, pneu (nc) 500# rn bdv (III) 045116 1
20 gasket, asa flange 300# 2-1/2” 240620-007 2
21 element, primary 25-200 (IV) 250034-121 1
22 element, sep/sec (V) 250034-133 1
23 tank, 20” dia oil sep 400# 250041-023 1
24 tee, reducing 300# 2 1/2 x 2 x 2 1/2 806710-080 1
(I) For maintenance on assembly filter no. 02250117-782, order replacement filter no. 02250117-782.
(II) For maintenance on discharge/check valve sub-assembly no. 02250126-832, order repair kit no. 606208-
001.
(III) For maintenance on blowdown valve no. 045116, order repair kit no. 047524.
(IV) For maintenance on primary separator element no. 250034-121, order replacement element no.
250034-122.
(V) For maintenance on secondary separator element no. 250034-133, order replacement element no.
250034-134.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
Continued on page 71
