Sullair SUPERVISOR CONTROLLER Series User Manual

5
Section 2
SUPERVISOR DESCRIPTION
2.1 SUPERVISOR KEYBOARD LAYOUT
Refer to Figure 2-1. The Display module has eleven
keys grouped in two rows.
The top row has the following seven keys :
- Help key, used to display possible causes of
and correction for an alarm or fault.
- Returns to main display.
-Used to edit text or numbers (move cursor
left).
- Used to edit text or numbers (move cursor
right).
- Used to change numbers or text, or scroll.
- Used to change numbers or text, or scroll.
- Used to select an item from a menu, or start
and end an edit on a parameter.
The bottom row has four keys :
- Stop, stops machine. Clears faults and warn-
ings if machine is stopped.
- Run, starts machine. Clears warnings if
machine is running.
- Toggles auto mode.
-Toggles Local/Remote mode. This can be
used to disable sequencing.
2.2 MAIN DISPLAY
Line 1 - Machine state :
E-Stop - E- Stop button pressed, or auxiliary e-
stop present.
Stopped - Machine not running.
Unloaded - Machine running unloaded.
Loaded - Machine running, loaded and modu-
lating.
Full Load - Machine forced to full load. (Used
only in sequencing modes).
Remote Stop - Compressor is off but armed to
start. The machine will start when the remote
start contact is closed. NOTE : the machine
may start at any time.
Seq Stop - Compressor is off but armed to
start. The machine will start when the sequenc-
ing conditions meet the criteria to start. NOTE:
the machine may start at any time.
Trim - Machine running, loaded and modulating
in a sequenced system.
Line 2 - Fault or Warning, blank means no fault or
warning is present.
If there are multiple alarms, they will be shown for 2
seconds each. If an alarm is active, pressing the ‘?’
key will give troubleshooting information on that
alarm.
Line 3 - P2 - Line pressure
Line 4 - T1 - Discharge Temperature
2.3 FUNCTION MENU
While in the main display, if any of the arrow keys
are pressed, the function menu is displayed. This
menu is used to view status or edit parameters.
The function menu has the following entries :
Status - Current pressures, temperatures, inputs
and outputs.
VSD Satus - (VSD packages only) See Section 6.
Control Parameters - Pressure and temperature
and timer settings.
Maintenance - Preventive maintenance informa-
tion and timers.
Fault Log - Log of previous faults.
Sensor Log - Log of sensor readings leading up to
a fault.
Sequencing - Sequencing parameters.
System Display - Display of modes of machines in
a sequencing system.
Calibration - Correction factors for pressures.
Test - Used by Sullair personnel for troubleshooting
serial communications.
Factory Setup - Model settings.
VSD Setup - (VSD Packages only) See Section 6.
To select a function, use the up and down arrow
keys to scroll to the desired function as indicated on
last line of display, then press the enter key.
After entering a function, the information can be
viewed by using the up and down arrow keys. If the
function shows status then values cannot be
changed. If the function displays parameters, then
the values can be changed.
To change a value, scroll to the line to be changed
