Sullair Supervisor II User Manual

Section 2
SUPERVISOR II DESCRIPTION
8
If there are alarms active they will alternately be
shown with the default display.The machine status
willbedisplayed for2seconds then the alarms for2
seconds each. For example:
T1 HI
110 180
To view other status press the DISPLY key. All tem-
peratures and pressures may be displayed as well
as other status information. To scroll through the
displays press the up arrow or down arrow keys.
Up arrow moves to the next display, down arrow
the previous display. Toreturn tothe default display
press the display key.
S
Separator differential pressure and the
maximum limit. If the limit is exceeded, a
separator maintenance warning willbedis-
played.
dP 1 4
MAX 10
S
Sump pressure and line pressure.
P1 113
P2 108
S
Oil filter differential pressure and the maxi-
mum limit. If the limit is exceeded oil main-
tenance warning will be displayed.
dP2 4
MAX 20
S
Pressure before(P4)and after(P3)oilfilter.
P3 108
P4 113
S
Oil differential pressure and the minimum
limit. If the pressure goes below the limit a
P3LOWshutdown will occur.Oildifferential
(dP3) is defined as P3---P1/2
dP3 40
MIN 1
S
Unit discharge temperature and the maxi-
mum limit. If the temperature exceeds the
limit a T1 HI shutdown will occur.
T1 210
MAX 235
S
Dry side discharge temperature and the
maximum limit. If the temperature exceeds
the limit a T2 HI shutdown will occur.
T2 210
MAX 235
S
Oiltemperature and the maximum limit.
If the temperature exceeds the limit a T3HI
shutdown will occur.
T3 210
MAX 235
S
Total hours that thecompressor hasbeen
running.
HRS RUN
001234.0
S
Totalhoursthatthecompressor has been
loaded.
HRS LOAD
000987.0
S
Last fault log. This shows the fault on the
first line and the run hours when the fault
occcured.
T1 HI
@1 234
S
Next to last fault log. This shows the fault
on the first line and the run hours when the
fault occcured.
T1 HI
@2 204
2.3 D STATUS DISPLA YS --- TS --- 20 & TS --- 32
By default the line pressure (P2) and discharge
temperature (T1) are shown on the bottom line of
the display, and machine status on the top line.
The following are the various machine status mes-
sages that indicate the state of the compressor:
(Display graphics shown below.)
S
STOP
--- Compressor is off.
S
ST ANDBY
--- Compressor isoffbutarmed
tostart. Thisstate maybeentered because
of a power up, or the unload timer had ex-
pired and stopped the machine. NOTE :
The machine may start at any time.
S
STARTING
--- Machine is trying to start.
S
OFF LOAD
--- Machine is running and off
loaded.
S
ON LOAD
--- Machine is running and
loaded.
