Sullair Supervisor II User Manual

Section 2
SUPERVISOR II DESCRIPTION
11
T2 210
MAX 235
S
Oiltemperature and the maximum limit.
If the temperature exceeds the limit a T3HI
shutdown will occur.
T3 210
MAX 235
S
Interstage temperature and the maximum
limit. If the temperature exceeds the limit a
T4 HI shutdown will occur.
T4 210
MAX 235
S
Total hours that thecompressor hasbeen
running.
HRS RUN
001234.0
S
Totalhoursthatthecompressor has been
loaded.
HRS LOAD
000987.0
S
Last fault log. This shows the fault on the
first line and the run hours when the fault
occcured.
T1 HI
@1 234
S
Next to last fault log. This shows the fault
on the first line and the run hours when the
fault occcured.
T1 HI
@1 204
2.3 F STATUS DISPLAYS --- DS --- 13
By default the line pressure (P2) and discharge
temperature (T1) are shown on the bottom line of
the display, and machine status on the top line.
The following are the various machine status mes-
sages that indicate the state of the compressor:
(Display graphics shown below.)
S
STOP
--- Compressor is off.
S
ST ANDBY
--- Compressor isoffbutarmed
tostart. Thisstate maybeentered because
of a power up, or the unload timer had ex-
pired and stopped the machine. NOTE :
The machine may start at any time.
S
STARTING
--- Machine is trying to start.
S
OFF LOAD
--- Machine is running and off
loaded.
S
ON LOAD
--- Machine is running and
loaded.
S
FULL LD
--- Machine is running and fully
loaded. This state is only displayed if the
machine has a full load valve.
S
RMT STOP
--- Compressor is off but
armed tostart. The machine will start when
the remote start contact is closed. NOTE :
the machine may start at any time.
S
SEQSTOP
--- Compressor isoffbutarmed
tostart. The machine will start when the se-
quencing conditions meet the critera to
start. NOTE : the machine may start at any
time.
This default display appears as follows:
STOP
110 350
If there are alarms active they will alternately be
shown with the default display.The machine status
willbedisplayed for2seconds then the alarms for2
seconds each. For example:
T1 HI
110 350
To view other status press the DISPLY key. All tem-
peratures and pressures may be displayed as well
as other status information. To scroll through the
displays press the up arrow or down arrow keys.
Up arrow moves to the next display, down arrow
the previous display. Toreturn tothe default display
press the display key.
S
Interstage discharge pressure and line
pressure.
P1 30
P2 110
S
Oil filter differential pressure and the maxi-
mum limit. If the limit is exceeded oil main-
tenance warning will be displayed.
dP2 4
MAX 20
S
Pressure before(P4)and after(P3)oilfilter.

Sullair Supervisor II Specifications

General

Brand	Sullair
Model	Supervisor II
Category	Controller
Language	English
