Sumitomo Beier Variator Series User Manual

21
8-4) Oil Supply and Change for Oil-lubricated CYCLO
(1) Oil Change Interval
Table 23 Interval
Table 24 Recommended Lubricating Oil For A Type and B Type BEIER-CYCLO Variator
(3) Oil Quantity
Table 26 shows approx. quantity of oil. Be sure to check the oil level through the oil gauge.
COMMON
(2) Recommended Lubricants
Be sure to use a lubricant recommended by our company.
Recommended lubrication oil is the same for BEIER part and CYCLO part of A Type and B Type BEIER-CYCLO Variator .
Use designated traction oil in Table 18 for BEIER part and use recommended lubrication oil for Cyclo in Table 24 for
D Type (ND Series) BEIER-CYCLO Variator .
Always use correct lubrication oil for both D Type (ND Series) BEIER part and CYCLO part because using mixed or
incorrect oil can affect performance and life significantly.
1 For operation in winter or at a relativery low ambient temperature, use lubricating oils with lower viscosity.
2 Table 25 shows selection standard for viscosity of lubricating oil.
Min allowable viscosity
Max allowable
viscosity
Above 15mm/s at oil temp, during operation
Viscosity to obtain the oil film needed for transmission of the load
Viscosity that allows CYCLO to start
Viscosity that allows plunger pumps and trochoid pumps to start
Oil bath lubrication
models
less than 4300mm
2
/s
Forced oil lubrication
models
less than 2200mm
2
/s
Table 25 Selection Standard for the Oil Viscosity of CYCLO Part
3 To ensure smooth start, use lubricating oil whose pour point is at least 5°C lower than embient temperature.
4 If ambient temperature varies over a wide range, use lubricating oil whose viscosity remains stable or lubricating oil
that will satisfy requirments in Notes 2 and 3 in high viscosity index.
5 When units are always used at an ambient temperature other than 0 to 40°C, consult with the factory because
depending on models it may need to change some parts or preheat or cool lubricating oil.
Table 26 Amount of Lubricating Oil (L)
Ambient
Temperature
-10°C – 5°C
0°C– 35°C
30°C – 50°C
Shell Oil
Shell Tellus
S2 M 46, 68
Shell Tellus
S2 M 100
Shell Morlina
S2 B 150
Shell Morlina
S2 B 220
Nuto H 68
Teresso 100, 150
Teresso 220, 320
Exxson Mobil
Mobil DTE 25, 26
(ISO VG46, 68)
Mobil DTE
Oil Heavy
(ISO VG100)
Mobil Vacuoline 528
(ISO VG150)
Mobil Vacuoline
533,537
(ISO VG220, 320)
Single
reduction
Frame
size
Horizontal
Vertical
6075
Grease
Grease
6125DB
Grease
Grease
Double
reduction
Frame
size
Horizontal
Vertical
6130DB
6135DB
6130DC
6135DC
6160DA
6165DA
6160DB
6165DB
6170DB
6175DB
6180DA
6185DA
6160DC
6165DC
1.5
1.0
6170DC
6175DC
2.4
1.9
6180DB
6185DB
3.5
2.0
6190DA
6195DA
5.8
2.7
6190DB
6195DB
6.0
2.7
6205DA
6205DB
6.0
11
6215DA
6215DB
10
14
6225DA
6225DB
11
18
6235DA
6235DB
17
23
6245DA
6245DB
18
29
6255DA
6255DB
23
42
6265DA
32
51
6275DB
60
60
6095 6105 6125 6135
0.7
1.1
6145
0.7
1.1
6165
1.4
1.0
6175
1.9
1.9
6185
2.5
2.0
6195
4.0
2.7
6215
8.5
7.5
6225
10
10
6235
15
12
6245
16
15
6255
21
42
6265
29
40
6275
56
60
In the case where the ambient temperature is high, there is intense change in temperature, or the air contains corrosive gas
consult the oil producter. These situations may accelerate the deterioration of the oil.
Task
Supply of oil
Oil change
Conditions of use
common
common
Indoor temperature is 0–35C°
Location where temperature cannot be kept
at 0–35C°
Conditions interval
At purchase
500 hrs operation or 6 months, whichever comes first.
5000 hrs operation or 1 year, whichever comes first.
2500 hrs operation or 6 months, whichever comes first.
First change
Second change and
thereafter
