Press the button
on the Control Panel.
The word “Level” will
light up, indicating that
you need to adjust the
base angle.
Press the Recline
Adjustment Buttons on
both sides of the Control
Panel while lifting or
lowering the base until a
appears. Ideally the
“level to ground” line
on the side of the base
should be level to the
ground.
Remove excess slack
and pull snug.
MAKE SURE:
1. LAP portion only is
routed through Spool.
2. LAP and
SHOULDER portions
are routed through
Tension Sensor.
Base Installation
39
Base Installation
38
CARRIER IS INSTALLED IN
VEHICLE WITH THE BASE.
LATCH
STORAGE
LINE MUST BE LEVEL WITH GROUND
WHEN
21110-L22
NEXT
9
NEXT
10
press!press!
press!
press!
CARRIER IS INS
T
ALLED IN
VEHICLE
WITH
THE BASE.
LATCH
STORAGE
LINE MUST BE LEV
EL
WITH GROUND
WHEN
21110-L22
lock
vehicle
belt!
lock
vehicle
belt!
LOCK YOUR
VEHICLE SEAT
BELT!
REFER TO page 22 of
this User Guide and to
your vehicle owner’s
manual for more
information regarding
locking your vehicle
belt.
If you have an ELR (Emergency Locking
Retractor) with a sliding latch plate, a
LOCKING CLIP must be used. Please refer
to page 42 of this User Guide for more
detailed installation instructions.
Shown: Switchable Retractor
pull snug!
pull snug!
To Next Page
