Page 10 MPE-200 Guide to Operations
3.2 HP/LP FILTER screen (amber).
Highpass filter at 20 Hz and
lowpass filter at 30 kHz selected
This screen controls the two 12 dB/octave filter sections of the
MPE Mic Preamps. Each filter can be highpass or lowpass, and if
both are set to the same frequency, the resulting slope is 24
dB/octave. Push the knob to select either filter. Rotate the knob to
select the desired frequency, or an off position. When off, these
filters are completely removed from the signal path.
[
*
]
The filter settings shown are applied to the active
channels(s) determined by the Master channel selector
(see section 5.1), not the channel(s) selected on the mic
gain screen.
20 30
Hz kHz
