MPE-200 Guide to Operations Page 5
1.5 AUDIO CONNECTIONS
Mic and Eq inputs and outputs are all balanced and floating,
using standard 3-pin connectors on the rear panel. Outputs
are transformer coupled.
To interface unbalanced equipment, connect signal to pin 2,
and tie pin 3 to pin 1. The inputs will also work if connected
'pin 3 hot', but the phase will be inverted.
The Mic inputs can accept up to +21 dBu (+18 dBu if
unbalanced) when set to zero gain, and can be used with
most line level signals. The Mic Pre outputs are always
active. When Eq In is selected, you can insert external
equipment between the Mic Pre outputs and the EQ inputs.
See section 3.3 for details.
INPUT / OUTPUT SPECIFICATIONS
Mic In:
Impedance: 10k ohms
Maximum input level +21 dBu
(at 0 gain)
Line In:
Impedance: 10k ohms
Maximum input level +21 dBu
(at 0 gain)
Outputs:
Maximum level +24 dBu
(internal jumper installed) +28 dBu
All outputs are balanced and transformer isolated
