Sun Microsystems GDM-5010PT User Manual

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
GDM-5010PT
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
R913 1-219-748-11 CARBON 4.7K 5% 1/2W
R914 1-219-510-11 CARBON 470K 5% 1/2W
R915 1-249-437-11 CARBON 47K 5% 1/4W
R916 1-249-429-11 CARBON 10K 5% 1/4W
R917 1-216-073-00 RES,CHIP 10K 5% 1/10W
R918 1-216-097-91 RES,CHIP 100K 5% 1/10W
R919 1-216-025-91 RES,CHIP 100 5% 1/10W
R920 1-249-401-11 CARBON 47 5% 1/4W F
R921 1-216-668-11 METAL CHIP 5.1K 0.50%1/10W
R922 1-216-041-00 RES,CHIP 470 5% 1/10W
R923 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R924 1-249-397-11 CARBON 22 5% 1/4W F
R925 1-216-653-11 METAL CHIP 1.2K 0.50%1/10W
R926 1-216-653-11 METAL CHIP 1.2K 0.50%1/10W
R927 1-216-073-00 RES,CHIP 10K 5% 1/10W
R928 1-216-667-11 METAL CHIP 4.7K 0.50%1/10W
R929 1-216-033-00 RES,CHIP 220 5% 1/10W
R930 1-216-033-00 RES,CHIP 220 5% 1/10W
R933 1-216-683-11 METAL CHIP 22K 0.50%1/10W
R934 1-216-667-11 METAL CHIP 4.7K 0.50%1/10W
R937 1-219-727-11 METAL 68 5% 10W
R940 1-249-393-11 CARBON 10 5% 1/4W F
R941 1-216-073-00 RES,CHIP 10K 5% 1/10W
R980 1-216-049-91 RES,CHIP 1K 5% 1/10W
R981 1-216-025-91 RES,CHIP 100 5% 1/10W
R1001 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1003 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1004 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1005 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1006 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1007 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1009 1-216-097-91 RES,CHIP 100K 5% 1/10W
R1011 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1012 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1013 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1014 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1015 1-216-295-91 SHORT 0
R1016 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1017 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1020 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1021 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1022 1-216-295-91 SHORT 0
R1023 1-216-295-91 SHORT 0
R1024 1-216-295-91 SHORT 0
R1025 1-249-389-11 CARBON 4.7 5% 1/4W F
R1026 1-249-389-11 CARBON 4.7 5% 1/4W F
R1027 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R1028 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1501 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1502 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1503 1-216-125-00 RES,CHIP 1.5M 5% 1/10W
R1504 1-216-097-91 RES,CHIP 100K 5% 1/10W
R1513 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1514 1-216-049-91 RES,CHIP 1K 5% 1/10W
<RELAY>
RY501 1-755-137-11 RELAY
<SPARK GAP>
SG701 1-519-422-11 GAP, SPARK
SG702 1-519-422-11 GAP, SPARK
SG901 1-517-499-21 GAP, SPARK
<TRANSFORMER>
T501 1-429-303-21 TRANSFORMER, FERRITE (HDT)
T502 1-416-401-11 INDUCTOR 0UH
T503 1-431-413-11 TRANSFORMER, FERRITE (HST)
T504 1-416-257-11 INDUCTOR 0UH
T701 1-431-414-11 TRANSFORMER, FERRITE (DFT)
T901 1-416-402-11 INDUCTOR 0UH
T902 ¡ X-4035-170-1 TRANSFORMER ASSY, FLYBACK
(NX-4142//J1D4)
<THERMISTOR>
TH501 1-807-796-11 THERMISTOR
TH502 1-807-796-11 THERMISTOR
<CRYSTAL>
X001 1-567-781-61 VIBRATOR, CRYSTAL
********************************************************************************
* 8-933-298-00 H1 BOARD, COMPLETE
******************************
<CAPACITOR>
C805 1-124-589-11 ELECT 47MF 20% 16V
C811 1-124-589-11 ELECT 47MF 20% 16V
<CONNECTOR>
CN801*1-564-526-11 PLUG, CONNECTOR 11P
CN802*1-564-509-11 PLUG, CONNECTOR 6P
<DIODE>
D810 8-719-064-11 DIODE SPR-325MVW
<TRANSISTOR>
Q801 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
D(h1)
7-14
