REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
GDM-5010PT
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
<RESISTOR>
R801 1-216-663-11 METAL CHIP 3.3K 0.50%1/10W
R802 1-216-639-11 METAL CHIP 330 0.50%1/10W
R803 1-216-639-11 METAL CHIP 330 0.50%1/10W
R804 1-216-643-11 METAL CHIP 470 0.50%1/10W
R805 1-216-643-11 METAL CHIP 470 0.50%1/10W
R806 1-216-647-11 METAL CHIP 680 0.50%1/10W
R807 1-216-651-11 METAL CHIP 1K 0.50%1/10W
R808 1-216-651-11 METAL CHIP 1K 0.50%1/10W
R809 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R810 1-216-663-11 METAL CHIP 3.3K 0.50%1/10W
R814 1-216-073-00 RES,CHIP 10K 5% 1/10W
R815 1-216-073-00 RES,CHIP 10K 5% 1/10W
R818 1-216-073-00 RES,CHIP 10K 5% 1/10W
R819 1-216-097-91 RES,CHIP 100K 5% 1/10W
R826 1-216-037-00 RES,CHIP 330 5% 1/10W
R827 1-216-031-00 RES,CHIP 180 5% 1/10W
<SWITCH>
S802 1-572-200-11 SWITCH, KEYBOARD (CONT+)
S803 1-572-200-11 SWITCH, KEYBOARD (CONT-)
S804 1-572-200-11 SWITCH, KEYBOARD (MENU)
S805 1-572-200-11 SWITCH, KEYBOARD (BRT+)
S806 1-572-200-11 SWITCH, KEYBOARD (BRT-)
S808 1-572-200-11 SWITCH, KEYBOARD (ASC)
<THERMISTOR>
TH801 1-807-796-11 THERMISTOR
********************************************************************************
* 8-933-299-00 H2 BOARD, COMPLETE
******************************
<CONNECTOR>
CN803*1-564-521-11 PLUG, CONNECTOR 6P
<DIODE>
D812 8-719-060-26 DIODE SLR-325YCT31
D813 8-719-060-26 DIODE SLR-325YCT31
<TRANSISTOR>
Q803 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q804 8-729-120-28 TRANSISTOR 2SC1623-L5L6
<RESISTOR>
R812 1-216-037-00 RES,CHIP 330 5% 1/10W
R813 1-216-037-00 RES,CHIP 330 5% 1/10W
R816 1-216-081-00 RES,CHIP 22K 5% 1/10W
R817 1-216-081-00 RES,CHIP 22K 5% 1/10W
R824 1-216-081-00 RES,CHIP 22K 5% 1/10W
R825 1-216-081-00 RES,CHIP 22K 5% 1/10W
<SWITCH>
S807 1-572-200-11 SWITCH, KEYBOARD (INPUT)
S810 1-572-200-11 SWITCH, KEYBOARD (RESET)
********************************************************************************
* 8-933-279-00 J BOARD, COMPLETE
****************************
<CONNECTOR>
CN891*1-691-961-11 PIN, CONNECTOR (PC BOARD) 2P
<SWITCH>
S891 ¡ 1-571-433-31 SWITCH, PUSH (AC POWER)
********************************************************************************
* 8-933-297-00 L BOARD, COMPLETE
****************************
<CAPACITOR>
C5002 1-126-964-11 ELECT 10MF 20% 50V
C5003 1-126-933-11 ELECT 100MF 20% 16V
C5004 1-104-664-11 ELECT 47MF 20% 25V
C5005 1-104-664-11 ELECT 47MF 20% 25V
C5008 1-104-664-11 ELECT 47MF 20% 25V
C5009 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5101 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5103 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5104 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5105 1-104-664-11 ELECT 47MF 20% 25V
C5106 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5107 1-137-399-11 FILM 0.1MF 5% 50V
C5108 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5109 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5110 1-104-664-11 ELECT 47MF 20% 25V
C5111 1-137-399-11 FILM 0.1MF 5% 50V
C5201 1-104-664-11 ELECT 47MF 20% 25V
C5202 1-104-664-11 ELECT 47MF 20% 25V
C5203 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5204 1-137-399-11 FILM 0.1MF 5% 50V
C5205 1-164-489-11 CERAMIC CHIP 0.22MF 10% 16V
C5206 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
(h1)(h2)JL
7-15
