REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
GDM-5010PT
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
C5301 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5303 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5304 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5305 1-104-664-11 ELECT 47MF 20% 25V
C5306 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5307 1-137-399-11 FILM 0.1MF 5% 50V
C5308 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5309 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5310 1-104-664-11 ELECT 47MF 20% 25V
C5311 1-137-399-11 FILM 0.1MF 5% 50V
C5401 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5403 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C5404 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5405 1-104-664-11 ELECT 47MF 20% 25V
C5406 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5407 1-137-399-11 FILM 0.1MF 5% 50V
C5408 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C5409 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5410 1-104-664-11 ELECT 47MF 20% 25V
C5412 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5501 1-126-923-11 ELECT 220MF 20% 10V
<CONNECTOR>
CN5001*1-564-512-11PLUG, CONNECTOR 9P
CN5002*1-564-509-11PLUG, CONNECTOR 6P
CN5003 1-564-513-11PLUG, CONNECTOR 10P
CN5004*1-564-507-11PLUG, CONNECTOR 4P
<DIODE>
D5002 8-719-801-78 DIODE 1SS184
D5101 8-719-800-76 DIODE 1SS226
D5103 8-719-800-76 DIODE 1SS226
D5201 8-719-800-76 DIODE 1SS226
D5301 8-719-800-76 DIODE 1SS226
D5303 8-719-800-76 DIODE 1SS226
D5401 8-719-800-76 DIODE 1SS226
D5403 8-719-800-76 DIODE 1SS226
D5501 8-719-976-96 DIODE DTZ4.7C
<SENSOR>
GS50011-475-592-11 SENSOR UNIT, MAGNETIC
<IC>
IC5101 8-759-822-38 IC LA6510
IC5201 8-759-803-42 IC LA6500-FA
IC5301 8-759-822-38 IC LA6510
IC5401 8-759-822-38 IC LA6510
<RESISTOR>
R5001 1-249-383-11 CARBON 1.5 5% 1/4W F
R5003 1-216-295-91 SHORT 0
R5005 1-216-689-11 RES,CHIP 39K 5% 1/10W
R5006 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5007 1-216-049-91 RES,CHIP 1K 5% 1/10W
R5008 1-216-295-91 SHORT 0
R5009 1-216-295-91 SHORT 0
R5010 1-216-295-91 SHORT 0
R5011 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5012 1-216-295-91 SHORT 0
R5013 1-216-295-91 SHORT 0
R5015 1-216-049-91 RES,CHIP 1K 5% 1/10W
R5101 1-249-383-11 CARBON 1.5 5% 1/4W F
R5102 1-249-383-11 CARBON 1.5 5% 1/4W F
R5108 1-216-308-00 RES,CHIP 4.7 5% 1/10W
R5109 1-216-308-00 RES,CHIP 4.7 5% 1/10W
R5110 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5111 1-216-308-00 RES,CHIP 4.7 5% 1/10W
R5112 1-249-383-11 CARBON 1.5 5% 1/4W F
R5113 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5114 1-249-441-11 CARBON 100K 5% 1/4W F
R5115 1-215-882-00 METAL OXIDE 22 5% 2W F
R5116 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5117 1-216-308-00 RES,CHIP 4.7 5% 1/10W
R5119 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5120 1-249-383-11 CARBON 1.5 5% 1/4W F
R5121 1-249-441-11 CARBON 100K 5% 1/4W F
R5122 1-215-882-00 METAL OXIDE 22 5% 2W F
R5201 1-249-383-11 CARBON 1.5 5% 1/4W F
R5202 1-249-383-11 CARBON 1.5 5% 1/4W F
R5203 1-249-383-11 CARBON 1.5 5% 1/4W F
R5204 1-249-441-11 CARBON 100K 5% 1/4W F
R5205 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5206 1-215-859-00 METAL OXIDE 22 5% 1W F
R5207 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5208 1-216-670-11 METAL CHIP 6.2K 0.50%1/10W
R5301 1-249-383-11 CARBON 1.5 5% 1/4W F
R5302 1-249-383-11 CARBON 1.5 5% 1/4W F
R5308 1-216-308-00 RES,CHIP 4.7 5% 1/10W
R5309 1-216-308-00 RES,CHIP 4.7 5% 1/10W
R5310 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5311 1-216-308-00 RES,CHIP 4.7 5% 1/10W
R5312 1-249-383-11 CARBON 1.5 5% 1/4W F
R5313 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5314 1-249-441-11 CARBON 100K 5% 1/4W F
R5315 1-215-882-00 METAL OXIDE 22 5% 2W F
R5316 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5317 1-216-308-00 RES,CHIP 4.7 5% 1/10W
R5319 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5320 1-249-383-11 CARBON 1.5 5% 1/4W F
R5321 1-249-441-11 CARBON 100K 5% 1/4W F
R5322 1-215-882-00 METAL OXIDE 22 5% 2W F
R5401 1-249-383-11 CARBON 1.5 5% 1/4W F
R5402 1-249-383-11 CARBON 1.5 5% 1/4W F
R5406 1-216-689-11 RES,CHIP 39K 5% 1/10W
R5407 1-216-079-00 RES,CHIP 18K 5% 1/10W
R5408 1-216-308-00 RES,CHIP 4.7 5% 1/10W
L
7-16
