Chapter 5 FC Module FRUs 5-5
FIGURE 5-2 Hardware Connections on the Back of a Dual-Controller Sun StorEdge 3511 FC Array
Management is in-band through fibre host connections and out-of-band through the
serial port and Ethernet port on the back of each controller.
FC devices
Servers and consoles
Management
console
FC expansion units/FC arrays
FC device connections
application/data servers and consoles
