Chapter 2 Cabinet and Rack Specifications 7
Weight
The total weight of a populated Sun StorEdge Expansion cabinet depends on the
number and type of modules installed in the cabinet.
TABLE 2-3 lists the weight of an
empty cabinet and the maximum weight of each J4200 component, and
TABLE 2-4
lists the weight of an empty cabinet and the maximum weight of each J4400
component. Use these weights to estimate the total weight of your system, based on
the number of modules installed in the cabinet. Record the total weight in an easy-
to-find place to reference when checking flooring load or elevator weight
restrictions.
TABLE 2-3 Sun StorEdge Expansion Cabinet and J4200 Component Weights
Component Quantity Weight
(each)
Total Component Weight
(lbs or kg)
Cabinet 1 X 350 lbs
*
(159 kg)
* Weight of an empty cabinet and two power sequencers.
= 350 lbs or 159 kg
J4200 Tray X 20.04 lbs (9.09 kg) =
SIM Board X 2.66 lbs (1.21 kg) =
Power Module X 4.87 lbs (2.21 kg) =
Fan Module X 0.94 lbs (0.43 kg) =
SAS Drive X 1.88 lbs (0.854 kg) =
SATA Drive X 1.83 lbs (0.833 kg) =
Total Weight
=
TABLE 2-4 Sun StorEdge Expansion Cabinet and J4400 Component Weights
Component Quantity Weight
(each)
Total Component Weight
(lbs or kg)
Cabinet 1 X 350 lbs
*
(159 kg)
* Weight of an empty cabinet and two power sequencers.
= 350 lbs or 159 kg
J4400 Tray X 31.28 lbs (14.19 kg) =
SIM Board X 3.81 lbs (1.73 kg) =
Power Module X 9.54 lbs (4.33 kg) =
SAS Drive X 1.88 lbs (0.854 kg) =
SATA Drive X 1.83 lbs (0.833 kg) =
Total Weight
=
