Vibration and Shock
Table 3-6 lists the vibration and shock specifications for the J4200 array, and Table 3-7
lists the vibration and shock specifications for the J4400 array.
TABLE 3-6 J4200 Shock and Vibration
TABLE 3-7 J4400 Shock and Vibration
Condition Parameter Specification
Vibration Operating 0.25 G (peak), 3 to 200 Hz sweep @ 1/2 octave per
minute, bottom side tested only
Nonoperating (unpacked) 10 Hz to 250 Hz, 1.54 GRMS random vibration, 15
minutes, 3 axes
Transit and storage (packed) 2 Hz to 200 Hz, 0.8 GRMS random vibration, 30 minutes,
6 axes
Shock Operating (no damage) 31-G +/-5%, with pulse duration of 2.6 ms or less half-
sine, bottom side tested only
Nonoperating 71-G +/-5%, with pulse duration of 2.0 ms or less half-
sine, all six sides tested
Transit (packed) Height 24.015 in. (610 mm), six sides, two corners, six
edges
Condition Parameter Specification
Vibration Operating 0.25 G (peak), 3 to 200 Hz sweep @ 1/2 octave per
minute, bottom side tested only
Nonoperating (unpacked) 10 Hz to 250 Hz, 1.54 GRMS random vibration, 15
minutes, 3 axes
Transit and storage (packed) 2 Hz to 200 Hz, 0.8 GRMS random vibration, 30 minutes,
6 axes
Shock Operating (no damage) 31-G +/-5%, with pulse duration of 2.6 ms or less half-
sine, bottom side tested only
Nonoperating 71-G +/-5%, with pulse duration of 2.0 ms or less half-
sine, all six sides tested
Transit (packed) Height 17.992 in. (457 mm), six sides, two corners, six
edges
