Top and Bottom Panels 17
4 Hardware Reference
Top and Bottom Panels
Detector array Electronics Connector
panel
Setup and
calibration markers
Figure 4-1. MapCHECK 3 Top Panel
ElectronicsDetector array
Threaded hole for
IMF/GMF
mounting
Threaded hole for
IMF/GMF
mounting
Threaded hole for
IMF/GMF
mounting
Threaded hole for
IMF/GMF
mounting
Figure 4-2. MapCHECK 3 Bottom Panel
