2.2 Installation Dimension
2.2.1 Dimension
Suitable model：E300-2S0007(B)~2S0022(B) / E300-4T0007(B)~4T00037(B) as fig 2-2-B.
Fig 2-2-A Inverter installation dimension typeⅠ
Suitable model：E300-2S0002(B) / E300-2S0004(B) as fig 2-2-A.
W1
W
H1
H
D
Fig 2-2-B Inverter installation dimension type Ⅱ
W1
W
D
H1
H
