6 DESCRIPTION OF SPECIFIC FUNCTIONS
6.1 Basic operation parameter unit
F0.0 Freq input channel/mode selection Setting range：0 ~ 4
Select setting channel/mode of inverter running freq.
0： Digital set
Inverter setting freq is set by parameter [F0.1].
1： External input signal
Running freq is set by external input volt signal (0~10V) or current signal (0~20mA). Please refer
to parameter [F1.0] and [F1.1] for explanation of relative characteristics.
2： Serial communication terminal
By serial RS485 interface, receive freq setting order from PC or master.
3： Panel potentiometer
Running freq is set by panel potentiometer.
4： External terminal selection
By external multi-function terminals, confirm freq input channel (selection of function terminal is
set by parameter [F1.7]～[F1.9]).
Freq set selects terminal 2 Freq set selects terminal 1 Freq setting channel
0 0 Digital set
0 1 External input signal (0~10V/0~20mA)
1 0 RS485 interface
1 1 Panel potentiometer
Note: Terminal and CM closed is valid as 1.
F0.1 Freq digital set Setting range：0.0 Hz ~upper freq
When freq input channel selects digital set ([F0.0] = 0), inverter output freq is controlled by this
value. Under operation panel normal monitor mode, press key to modify this parameter
directly.
F0.2 Operation channel and mode selection Setting range：0000 ~ 1122
Select inverter operation order channel and the function of key .
1
st
of LED：Operation order channel selection
0：Keypad control
STOP
RUN
E300 Series Mini-type Integrated Universal Inverter Manual
