SUNFAR E300 SERIES 27
Function definition of switch value input terminal X1～X3. Explanation as bellow:
0： Control terminal idle
1： Multi-speed control 1
2： Multi-speed control 2
3： Multi-speed control 3
Combination of multi-speed control terminal is used for selection multi-speed output freq. Each
step freq is set by multi-speed control parameter function code unit ([F3.0]～[F3.6]).
4： FWD jog control
5： REV jog control
When running order channel selects external terminal valid, this parameter defines external jog
signal input terminal.
6： Freq set channel selection 1
7： Freq set channel selection 2
When freq input channel selects (F0.0=4), inverter freq set channel is controlled by the two
terminals state. The corresponding relation refers to parameter [F0.0] for explanation.
8： Free stop control
Close this parameter corresponding terminal that inverter will lock output.
9： Three-line mode running control
When running order terminal combination mode selects three-line mode, the external
terminal defined by this parameter is inverter stop trigger switch. Three-line control mode
refers to function code [F0.2] for explanation.
10： DC braking control
When inverter stops, if the terminal defined by this parameter is closed, it will start DC
braking function till this terminal cuts when output freq is lower than DC braking initial freq.
DC braking relative parameters refer to [F2.3] ~[F2.5] for explanation.
11： REV control
12： Failure reset
External terminal defined by this parameter can achieve failure reset.
F1.10 Reserved
F1.11 Output terminal OC function selection Setting range：0 ~ 8
F1.12 Relay output TA/TB/TC function selection Setting range：0 ~ 8
E300 Series Mini-type Integrated Universal Inverter Manual
