Function Parameter Table 29
E500 Series Universal Low-Power Inverter
Parameter
Type
Function
Code
Name
Setting Range and
Description
Minimum
unit
Default
setting
Modifica-
tion limit
PID
F5.09
PID adjustment
frequency range
0.0~100.0% 0.1 100.0
F5.10
Breakage
detection value
0.0~50.0% 0.1 5.0
F5.11
Breakage
detection delay
time
0.1~10.0 Sec 0.1 5.0
F5.12
-
F5.22
Reserve
Special function
F6.00
Cutting function
selection
0: Drag 1: Cut 1 0
F6.01 Cutting length 0.100~2.000 0.001 0.700
F6.02
Correction of
liner speed
coefficient
0.100~10.000 0.001 1.000
F6.03 Start delay 0.01~10.00 0.01 3.00
F6.04 Stop delay 0.01~10.00 0.01 4.00
F6.05 Reserve
F6.06
Liner cutting
operating mode
0~2 1 0
F6.07 Forward time 0~60.0S 0.1 5.0
F6.08 Backward time 0~60.0S 0.1 4.0
F6.09
High-frequency
relay
Start frequency
[F6.10]~100% 1 99
F6.10
High-frequency
relay
Disconnection
frequency 1
0~[F6.09] 1 98
F6.11
High-frequency
relay
Disconnection
frequency 2
100~200% 1 120
Note: (1) E500 series standard model does not has this function, and only some
derived models have such function.
